Magna Power SLx10-800-12.5/208 is a 10kW programmable DC power supply with 800V/12.5A output, 208VAC input, and comprehensive digital control architecture.
Product details
| Model | SLx10-800-12.5/208 |
| Manufacturer | Magna Power |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The Magna Power SLx10-800-12.5/208 is a 10kW programmable DC power supply designed for research and development, industrial automation, and process control applications. Featuring 800V/12.5A output capacity with 208VAC single-phase input, it combines industry-leading power density with rugged current-fed power processing and advanced MagnaLINK distributed DSP digital control architecture.
Key Features
- 10kW continuous power output
- 800VDC maximum output voltage
- 12.5ADC maximum output current
- 208VAC single-phase input
- 16-bit precision with single bit control
- Voltage, current, and power control
- SCPI and Modbus command sets
- Programmable protection features with interlock and hardware emergency stop
- Slew rate control
- Continuous full power operation up to 50°C ambient
- Configurable analog-digital 26-pin I/O port
- Digital-hybrid MagnaLINK master-slaving
- Local, remote, and leadless voltage sensing
- USB (front and rear) and RS485 interfaces standard
- CAN, EtherCAT, EtherNet/IP, ModbusTCP, and PROFINET communications available
- MagnaCTRL software platform included
- Made in the USA
Applications
- Research and development testing
- Industrial automation and process control
- Manufacturing equipment power
- Laboratory benchtop applications
- System integration and multi-unit configurations
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 800 V |
| Current Range Selector | 10-19.9 |
| Output Current | 12.5 A |
| Power Range Selector | 10,000-19,999 |
| Power Rating | 10 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 208 VAC |
| Series | SLx Series |
| Display | Digital |
| Interface | RS-232 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 1U |
