ITECH IT6953A DC Power Supply
Request a quote
ITECH IT6953A is a 600W programmable DC power supply with 150V/10A output, designed for high-voltage applications including DC-DC module testing and battery system validation.
Product details
| Model | IT6953A |
| Manufacturer | ITECH |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The ITECH IT6953A is a 600W programmable DC power supply from the IT6900A series, delivering 150V/10A output for high-voltage applications. It is particularly suited for advanced testing scenarios including DC-DC module validation, high-voltage battery systems, and precision sensor testing.
Key Features
- High-voltage capability (150V) with stable output regulation
- Digital precision with adjustable step values via cursor
- Voltage and current control via front panel knob or numerical keypad
- Output Timer function (0.1 - 99999.9S) for automated test sequences
- Low ripple and low noise output
- Remote Sense function to eliminate wire drop errors
- Standard RS232 and USB communication interfaces with SCPI protocol
- VFD display for real-time monitoring
- Front and rear panel output options
- Intelligent cooling for continuous operation
Applications
- High-voltage DC-DC power supply module testing
- Advanced battery system development and testing
- Precision sensor and component validation
- High-voltage circuit analysis and troubleshooting
Specifications
| Voltage Range Selector | 100-199 |
| Output Voltage | 150 V |
| Current Range Selector | 10-19.9 |
| Output Current | 10 A |
| Power Range Selector | 500-999 |
| Power Rating | 600 W |
| Mounting Type | Bench Top |
| Input Voltage | 110/220 VAC |
| Series | IT6900A Series |
| Display | VFD |
| Includes | Power cord, USB cord, Factory calibration certificate |
| Interface | GPIB,USB,RS-232 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Special Features | Autoranging, Remote Sense |
