EA Elektro-Automatik EA-PSI 9200-04 DT DC Power Supply
Request a quote
EA Elektro-Automatik EA-PSI 9200-04 DT is a 200V/4A benchtop DC power supply with autoranging output, active PFC, function generator, and isolated digital interfaces.
Product details
| Model | EA-PSI 9200-04 DT |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PSI 9200-04 DT is a microprocessor-controlled benchtop DC power supply with 200 V / 4 A / 320 W output capacity. The autoranging output stage continuously adjusts voltage and current within the specified power limit, enabling flexible operation across a wide range of test, development, and production applications. A discharge circuit automatically reduces the output voltage to safe levels after shutdown.
Key Features
- Output: 200 VDC, 4 ADC, 320 W
- Autoranging power stage with adjustable maximum power setting
- Input: 90–264 V AC with active Power Factor Correction (PFC)
- Efficiency: up to 92%
- Touch-screen color display with full control and status monitoring
- Protections: Overvoltage (OVP), Overcurrent (OCP), Overpower (OPP), Overtemperature (OT)
- Galvanically-isolated interfaces: analog, USB, and Ethernet
- Integrated function generator with preset and arbitrary waveforms
- Internal resistance simulation and load regulation
- Low output ripple with integrated filter
- Safe discharge circuit for high-voltage models
- SCPI and Modbus RTU command support
- Desktop enclosure with carrying handle and tilt stand
Applications
- Development and production testing of electronic devices
- Research in power electronics and control systems
- Device characterization and burn-in testing
- Automated test and measurement systems
- Educational laboratory settings
Included Accessories
- Mains power cord with Schuko/UK plug (2 m)
- USB cable (1.8 m)
- USB stick with software and documentation
Specifications
| Voltage Range Selector | 200-299 |
| Output Voltage | 200 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 4 A |
| Power Rating | 320 W |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 15.39" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.6-960 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
