EA Elektro-Automatik EA-PSI 9080-60 DT DC Power Supply
Request a quote
EA Elektro-Automatik EA-PSI 9080-60 DT is an 80V/60A benchtop DC power supply with autoranging output, active PFC, function generator, and isolated digital interfaces.
Product details
| Model | EA-PSI 9080-60 DT |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PSI 9080-60 DT is a microprocessor-controlled benchtop DC power supply with 80 V / 60 A / 1500 W output capacity. The autoranging output stage continuously adjusts voltage and current within the specified power limit, enabling flexible operation across a wide range of test, development, and production applications.
Key Features
- Output: 80 VDC, 60 ADC, 1500 W
- Autoranging power stage with adjustable maximum power setting
- Input: 90–264 V AC with active Power Factor Correction (PFC)
- Efficiency: up to 92%
- Touch-screen color display with full control and status monitoring
- Protections: Overvoltage (OVP), Overcurrent (OCP), Overpower (OPP), Overtemperature (OT)
- Galvanically-isolated interfaces: analog, USB, and Ethernet
- Integrated function generator with preset and arbitrary waveforms
- Internal resistance simulation and load regulation
- Low output ripple with integrated filter
- SCPI and Modbus RTU command support
- Desktop enclosure with carrying handle and tilt stand
Applications
- Development and production testing of electronic devices
- Research in power electronics and control systems
- Device characterization and burn-in testing
- Automated test and measurement systems
- Educational laboratory settings
Included Accessories
- Mains power cord with Schuko/UK plug (2 m)
- USB cable (1.8 m)
- USB stick with software and documentation
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 80 V |
| Current Range Selector | 50-99.9 |
| Output Current | 60 A |
| Power Range Selector | 1,000-2,499 |
| Power Rating | 1.5 kW |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 17.75" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.05-40 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
