EA Elektro-Automatik EA-PSI 9080-10 DT DC Power Supply
Request a quote
EA-PSI 9080-10 DT benchtop autoranging DC power supply delivering up to 80V/10A (320W) with active PFC, comprehensive protections, and integrated function generator.
Product details
| Model | EA-PSI 9080-10 DT |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PSI 9080-10 DT is a microprocessor-controlled benchtop DC power supply from the PSI 9000 DT series. It delivers up to 80V and 10A output (320W maximum power) with flexible autoranging capability, allowing higher voltage at lower current or higher current at lower voltage within the power limit. The unit includes active Power Factor Correction (PFC) for worldwide operation (90-264 VAC input) and comprehensive protection functions for reliable testing and development work.
Key Features
- Autoranging output: 0-80V/0-10A, 320W maximum, adjustable power limit
- Wide AC input: 90-264 VAC with active PFC for worldwide use, up to 92% efficiency
- Protections: Overvoltage (OVP), overcurrent (OCP), overpower (OPP), and overtemperature protection
- Color TFT touch-panel display for intuitive control and real-time monitoring
- Integrated arbitrary function generator with sequence capability (up to 99 sequences)
- Galvanically-isolated interfaces: analog (0-10V control), USB, and Ethernet
- Low-ripple DC output with built-in additional filter for clean power delivery
- SCPI command set and ModBus RTU support for remote operation
- Desktop enclosure with carrying handle and tilt stand
- Included Windows PC control software with multi-unit support and data logging
Applications
- Laboratory testing and verification
- Product development and design validation
- Manufacturing and production testing
- Battery and power-system characterization
- Device prototype evaluation
- Electronic component testing
Included Accessories
- 2-meter mains cord (Schuko and/or UK plug, region-dependent)
- USB cable (1.8 m)
- USB stick with control software and documentation
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 80 V |
| Current Range Selector | 10-19.9 |
| Output Current | 10 A |
| Power Rating | 320 W |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 15.39" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.1-160 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
