EA Elektro-Automatik EA-PSI 9040-60 DT DC Power Supply
Request a quote
EA-PSI 9040-60 DT benchtop autoranging DC power supply delivering up to 40V/60A (1500W) with active PFC, integrated protections, and touch-panel control.
Product details
| Model | EA-PSI 9040-60 DT |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PSI 9040-60 DT is a microprocessor-controlled benchtop DC power supply from the PSI 9000 DT series. It features autoranging output of up to 40V and 60A (1500W maximum power), active Power Factor Correction (PFC) for worldwide mains input (90-264 VAC), and comprehensive protection functions. The unit is ideal for laboratory, development, and production testing applications requiring flexible, precise power delivery.
Key Features
- Autoranging output stage: 40V/60A maximum, limited to 1500W
- Wide AC input: 90-264 VAC with active PFC (up to 92% efficiency)
- Protections: Overvoltage (OVP), overcurrent (OCP), overpower (OPP), and overtemperature protection
- Color TFT touch panel display for intuitive control and monitoring
- Integrated arbitrary function generator with sequence capability (up to 99 sequences)
- Multiple interfaces: galvanically-isolated analog, USB, and Ethernet
- SCPI command set and ModBus RTU support for remote control
- Low-noise output with built-in additional filter
- SELV-compliant (Safety Extra Low Voltage) for safe operation
- Desktop enclosure with carrying handle and tilt stand
- Included control software for Windows PC with multi-unit support
Applications
- Laboratory and benchtop testing
- Product development and design verification
- Manufacturing and production testing
- Battery charging and conditioning
- Equipment prototype testing
- Electronic device validation
Included Accessories
- 2-meter mains cord (Schuko and/or UK plug depending on destination)
- USB cable (1.8 m)
- USB stick with software and documentation
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 40 V |
| Current Range Selector | 50-99.9 |
| Output Current | 60 A |
| Power Range Selector | 1,000-2,499 |
| Power Rating | 1.5 kW |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 17.75" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.05-20 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
