EA Elektro-Automatik EA-PSI 9040-40 DT 1000W DC Power Supply
Request a quote
EA Elektro-Automatik EA-PSI 9040-40 DT 1000W is an autoranging benchtop DC power supply with 40V/40A output, 1000W power rating, and safety low voltage protection.
Product details
| Model | EA-PSI 9040-40 DT 1000W |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA-PSI 9040-40 DT 1000W is a benchtop programmable DC power supply from the EA-PS 9000 T series with increased power capacity compared to standard models. Featuring autoranging output capability and integrated safety low voltage protection, this unit is designed for laboratory and industrial applications requiring higher power levels with the convenience of a benchtop form factor and intuitive user interface.
Key Features
- Autoranging output stage with flexible power regulation up to 1000W
- 40V and 40A output capability
- Wide input voltage range: 100-240V AC with active power factor correction
- Microprocessor-controlled operation with touchscreen interface
- Safety low voltage protection integrated
- Supervision features including overvoltage, overcurrent, and overpower protection
- Over-temperature protection with automatic DC output shutdown
- Benchtop form factor for laboratory and field use
- Remote sensing and optional analog interface capabilities
- User profiles and PC control software included
Applications
- Higher-power laboratory testing applications
- Industrial equipment commissioning and testing
- Development and prototyping requiring sustained power
- Educational applications with elevated power demands
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 40 V |
| Current Range Selector | 30-49.9 |
| Output Current | 40 A |
| Power Range Selector | 1,000-2,499 |
| Power Rating | 1 kW |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 17.75" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.05-30 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
