EA Elektro-Automatik EA-PSI 9040-20 DT DC Power Supply
Request a quote
EA Elektro-Automatik EA-PSI 9040-20 DT is an autoranging benchtop DC power supply with 40V output, 20A current, 320W power rating, and safety low voltage protection.
Product details
| Model | EA-PSI 9040-20 DT |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA-PSI 9040-20 DT is a benchtop programmable DC power supply from the EA-PS 9000 T series, designed for laboratory and industrial applications requiring moderate power output with autoranging capability. The unit accepts standard AC input (100-240V) and delivers regulated DC output with integrated safety low voltage protection for user safety and equipment protection.
Key Features
- Autoranging output stage with flexible power regulation up to 320W
- Wide input voltage range: 100-240V AC with active power factor correction
- Microprocessor-controlled operation with touchscreen interface
- Intuitive front panel with rotary knobs for easy adjustment
- Safety low voltage protection integrated
- Supervision features including overvoltage, overcurrent, and overpower protection
- Over-temperature protection with automatic DC output shutdown
- Benchtop form factor for laboratory use
- User profiles for quick switching between commonly used settings
Applications
- Laboratory testing and development
- Equipment maintenance and troubleshooting
- Educational applications
- Small-scale industrial testing
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 40 V |
| Current Range Selector | 20-29.9 |
| Output Current | 20 A |
| Power Rating | 320 W |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 15.39" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.1-80 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
