EA Elektro-Automatik EA-PS 11500-06 2U DC Power Supply
Request a quote
EA Elektro-Automatik EA-PS 11500-06 is a compact 2U programmable DC power supply with 1500V/6A output, 3kW power, and advanced touchscreen control.
Product details
| Model | EA-PS 11500-06 2U |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PS 11500-06 is a compact 2U programmable DC power supply from the PS 10000 series, delivering 0–1500V at up to 6A with a maximum power output of 3kW. This unit features exceptional efficiency exceeding 95% and is designed for laboratory, R&D, and industrial testing applications where space is limited but high voltage is required.
Key Features
- Output voltage range: 0–1500V DC
- Output current range: 0–6A DC
- Maximum power: 3kW
- Efficiency: >95%
- Autoranging output stage for flexible voltage/current combinations
- 5-inch TFT color touchscreen with intuitive interface
- Regulation modes: CV, CC, CP with fast crossover
- Master-Slave bus for parallel operation (up to 64 units)
- Galvanically isolated Share-Bus for load distribution
- 16-bit ADC/DAC for high-resolution control and measurement
- Multiple interfaces: USB, Ethernet, analog programming
- Wide input: 110–240V ±10% single phase AC
- Active Power Factor Correction (~0.99)
Applications
- High-voltage component testing and characterization
- Capacitor and diode testing
- Research and laboratory measurements
- Electronic device validation
Included Accessories
- 2x Remote sensing plugs
- 1.8m USB cable
- DC terminal covers
- Sense terminal cover
- USB stick with documentation and software
- Cable tie for strain relief
Specifications
| Voltage Range Selector | 1,000-1,999 |
| Output Voltage | 1.5 kV |
| Current Range Selector | 5-9.9 |
| Output Current | 6 A |
| Power Range Selector | 2,500-4,999 |
| Power Rating | 3 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 110-240 VAC |
| Series | EA-PS 10000 2U Series |
| Number of Outputs | Single Output |
| Special Features | Autoranging |
