EA Elektro-Automatik EA-PS 11000-10 2U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 11000-10 is a compact 2U rackmount programmable DC power supply from the PS 10000 series. It converts single-phase AC power to regulated DC output with 0-1000V voltage and 0-10A current, delivering up to 3kW. The supply features autoranging technology, flexible output stages, and high efficiency, making it ideal for compact laboratory applications and bench-top testing environments where space is limited.

Key Features

• Output: 0-1000V, 0-10A, up to 3,000W
• Autoranging: flexible output stages for wide voltage and current range capability
• Single-phase AC input: 110-240V ±10%
• High efficiency: over 95% with active PFC (typical 0.99)
• 5-inch TFT color touch display with intuitive user interface
• Regulation modes: CV (constant voltage), CC (constant current), CP (constant power) with fast crossover
• 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
• Galvanically isolated Share-Bus and Master-Slave bus for parallel operation of up to 64 units
• Standard interfaces: USB, Ethernet, analog I/O (0-5V or 0-10V), SCPI and ModBus command languages

Applications

• Bench-top laboratory testing and development
• Compact production test systems
• Component and circuit testing in limited space environments
• Educational and training facilities
• Parallel configurations for increased power up to 1920kW

Included Accessories

• Power supply device
• 2x remote sensing plugs
• 1.8m USB cable
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• Cable tie for strain relief
