EA Elektro-Automatik EA-PS 10750-60 3U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10750-60 is a 3U rackmount programmable DC power supply from the PS 10000 series. It converts AC grid power to regulated DC output with 0-750V voltage and 0-60A current, delivering up to 15kW. The supply features autoranging technology, allowing it to maintain full power across a wide range of voltage and current combinations. With over 96% efficiency and active power-factor correction, it is suitable for laboratory applications, production testing, and high-power system integration.

Key Features

• Output: 0-750V, 0-60A, up to 15,000W
• Autoranging: flexible output stages maintain full power across variable voltage/current combinations
• Three-phase AC input: 208-480V ±10%
• High efficiency: over 96% with active PFC (typical 0.99)
• 5-inch TFT color touch display with intuitive user interface
• Regulation modes: CV (constant voltage), CC (constant current), CP (constant power) with fast crossover
• 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
• Galvanically isolated Share-Bus and Master-Slave bus for parallel operation of up to 64 units
• Standard interfaces: USB, Ethernet, analog I/O (0-5V or 0-10V)

Applications

• Relay and contactor testing in manufacturing
• Onboard charger (OBC) testing for automotive applications
• Laboratory power supply for research and development
• Production test systems requiring dynamic voltage and current control
• Multi-unit parallel systems for applications up to 1920kW

Included Accessories

• Power supply device
• 2x remote sensing plugs
• 1.8m USB cable
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• AC connector plug (clamp type)
• AC cable strain relief kit
