EA Elektro-Automatik EA-PS 10750-20 3U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10750-20 3U is a high-performance programmable DC power supply from the PS 10000 series, designed for demanding laboratory and production testing applications. This 3U rackmount unit converts three-phase AC input into regulated DC voltage with efficiency exceeding 96%, delivering 0–750V at 0–20A with a maximum output of 5 kW.

The supply features a 5-inch TFT color touchscreen for intuitive control and monitoring, supporting constant voltage (CV), constant current (CC), and constant power (CP) regulation modes with fast crossover. Its robust design and flexible autoranging capability make it ideal for relay testing, onboard charger validation, and high-power laboratory applications, with support for parallel operation of up to 64 units via Master-Slave bus for systems exceeding 1920 kW.

Key Features

• Output range: 0–750V, 0–20A, 5 kW with autoranging
• 3U 19-inch rackmount form factor
• 5-inch TFT color touchscreen display with touch control
• Input: 208–480V ±10% three-phase AC with active PFC
• Power output: up to 15 kW per unit with flexible power regulation
• Voltage range: 0–60V to 0–2000V; Current range: 0–20A to 0–510A
• Regulation modes: CV, CC, CP with fast mode switching
• Power factor correction: typical 0.99
• Efficiency: greater than 96%
• 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
• Galvanically isolated Share-Bus for parallel load distribution across all power classes
• Master-Slave bus supporting up to 64 parallel units of any power class
• Isolated analog I/O for external monitoring and control
• Function generator for complex test sequences
• USB and Ethernet connectivity with data logging

Applications

• Relay and contactor testing in manufacturing and validation
• Onboard charger (OBC) electrical verification under various conditions
• Component qualification and accelerated life testing
• Laboratory research and equipment development
• Multi-unit high-power systems up to 1920 kW via parallel connection
• Dynamic power simulation for complex load testing

Included Accessories

• Power supply device
• 2 x Remote sensing plugs
• 1.8 m USB cable
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• AC connector plug (clamp type)
• Set for AC cable strain relief
