EA Elektro-Automatik EA-PS 10750-06 2U DC Power Supply
EA Elektro-Automatik EA-PS 10750-06 2U programmable DC power supply with 750V/6A output, 1.5 kW power, autoranging capability, and 5-inch TFT touchscreen control.
Product details
| Model | EA-PS 10750-06 2U |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PS 10750-06 2U is a programmable laboratory DC power supply from the PS 10000 series, engineered for precision testing and system development. This 2U rackmount unit converts single-phase AC input into regulated DC voltage with efficiency exceeding 96%, delivering 0–750V at 0–6A with a maximum output of 1.5 kW.
The supply features a 5-inch TFT color touchscreen for intuitive control and monitoring, supporting constant voltage (CV), constant current (CC), and constant power (CP) regulation modes with fast crossover. It is designed for applications including relay testing, onboard charger validation, and laboratory research, with support for parallel operation of up to 64 units via Master-Slave bus.
Key Features
- Output range: 0–750V, 0–6A, 1.5 kW with autoranging
- 2U 19-inch rackmount form factor
- 5-inch TFT color touchscreen display with intuitive user interface
- Input: 110–240V ±10% single-phase AC with active PFC
- Regulation modes: CV, CC, CP with fast mode switching
- Power factor correction: typical 0.99
- Efficiency: greater than 95%
- 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
- Galvanically isolated Share-Bus for parallel load distribution
- Master-Slave bus supporting up to 64 parallel units
- Interface support: SCPI, ModBus, LabVIEW, IVI
- USB host port for data logging and sequencing via USB stick
- Rear Ethernet and USB connectivity
- Isolated analog I/O connector for external monitoring and control
- Remote voltage sensing for load regulation
Applications
- Relay and contactor testing in manufacturing
- Onboard charger (OBC) electrical validation
- Laboratory testing and research and development
- Component qualification and burn-in testing
- High-power systems via parallel multi-unit configurations
Included Accessories
- Power supply device
- 2 x Remote sensing plugs
- 1.8 m USB cable
- Set of DC terminal covers
- Sense terminal cover
- USB stick with documentation and software
- Cable tie for strain relief
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 750 V |
| Current Range Selector | 5-9.9 |
| Output Current | 6 A |
| Power Range Selector | 1,000-2,499 |
| Power Rating | 1.5 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 110-240 VAC |
| Series | EA-PS 10000 2U Series |
| Number of Outputs | Single Output |
| Special Features | Autoranging |
