EA Elektro-Automatik EA-PS 10500-20 Programmable DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10500-20 is a laboratory programmable DC power supply from the PS 10000 series. It delivers 0–500V and 0–20A with up to 3 kW output power. Featuring true autoranging, the supply maintains constant power across the voltage and current range, making it suitable for diverse test applications. Efficiency exceeds 96% with active power-factor correction.

Key Features

• Output: 0–500V DC, 0–20A, up to 3 kW power
• True autoranging for flexible voltage and current combinations
• 5-inch TFT color touch display with intuitive interface
• Regulation modes: CV (constant voltage), CC (constant current), CP (constant power) with fast crossover
• 16-bit ADCs and DACs with selectable control speed: Normal, Fast, Slow
• Wide AC input: 110–240V single-phase (±10%)
• Active power-factor correction (typical 0.99)
• Efficiency over 95%
• Master-Slave bus for parallel operation up to 64 units
• Galvanically isolated Share-Bus for parallel operation
• Interfaces: SCPI and ModBus command languages, LabVIEW, IVI drivers
• USB host for data logging and sequencing
• 2U 19-inch rackmount frame

Applications

• Laboratory and bench-top testing of electronic devices
• Relay testing and characterization during manufacturing
• Onboard charger functional testing
• Power conditioning and load testing
• Research and development applications

Included Accessories

• Power supply device
• 2 × Remote sensing plugs
• 1.8 m USB cable
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• Cable tie for strain relief
