EA Elektro-Automatik EA-PS 10360-80 3U DC Power Supply
EA-PS 10360-80 3U delivers 10 kW of DC power with 0-360V at up to 80A, autoranging capability, 96%+ efficiency, 3-phase input, and Master-Slave bus for parallel high-power systems.
Product details
| Model | EA-PS 10360-80 3U |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PS 10360-80 3U is a high-capacity programmable DC power supply from the PS 10000 series, engineered for demanding industrial and laboratory test applications requiring up to 10 kW output. It converts 3-phase AC mains (208-480V) into precisely regulated DC voltage with efficiency exceeding 96%, featuring true autoranging technology and Master-Slave architecture for scalable multi-unit systems.
The 3U rackmount design includes a 5-inch TFT color touch display, comprehensive digital and analog interfaces, and the capability to parallelize up to 64 units for applications exceeding 1920 kW, making it ideal for high-power industrial automation and research environments.
Key Features
- Output voltage 0 to 360V, current 0 to 80A, maximum power 10 kW
- High-performance 3-phase AC input 208-480V +10%
- True autoranging flexible output stages with constant power characteristic
- Efficiency exceeding 96% with active power-factor correction typical 0.99
- 5-inch TFT color touch display with touch control and intuitive user interface
- Regulation modes CV, CC, CP with fast crossover
- High-resolution 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
- Galvanically isolated Share-Bus and Master-Slave bus for parallel operation up to 64 units
- Comprehensive interfaces: USB, Ethernet, parameterizable analog I/O (0-5V or 0-10V)
- Advanced command languages: SCPI, ModBus with LabVIEW and IVI driver support
Applications
- Large-scale industrial power testing and production validation
- High-power relay and automotive component manufacturing tests
- Power electronics and battery charger development and qualification
- Parallel multi-unit systems for 75 kW+ industrial and research applications
- Automated test procedures with data logging and sequencing capabilities
Included Accessories
- Remote sensing plugs (pair)
- USB cable 1.8m (59 ft)
- Set of DC terminal covers
- Sense terminal cover
- USB stick with documentation and software
- AC connector plug (clamp type)
- Set for AC cable strain relief
Specifications
| Voltage Range Selector | 300-499 |
| Output Voltage | 360 V |
| Current Range Selector | 50-99.9 |
| Output Current | 80 A |
| Power Range Selector | 10,000-19,999 |
| Power Rating | 10 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 208-480 VAC |
| Series | EA-PS 10000 3U Series |
| Number of Outputs | Single Output |
| Special Features | Autoranging |
