EA Elektro-Automatik EA-PS 10360-40 3U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10360-40 3U is a high-power programmable DC power supply from the PS 10000 series, optimized for demanding laboratory and industrial test applications. It converts 3-phase AC mains (208-480V) into regulated DC voltage with efficiency exceeding 96%, delivering up to 5 kW of power with true autoranging technology for flexible voltage and current combinations.

The 3U form factor integrates a 5-inch TFT color touch display, galvanically isolated interfaces, and Master-Slave bus capability for seamless parallel operation of up to 64 units, enabling systems delivering up to 1920 kW for high-power test scenarios.

Key Features

• Output voltage 0 to 360V, current 0 to 40A, maximum power 5 kW
• High-performance 3-phase AC input 208-480V +10%
• True autoranging output stages with constant power characteristic
• Efficiency exceeding 96% with active power-factor correction typical 0.99
• 5-inch TFT color touch display with intuitive user interface
• Regulation modes CV, CC, CP with fast crossover
• 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
• Galvanically isolated Share-Bus and Master-Slave bus for parallel operation of up to 64 units
• Comprehensive digital and analog interfaces: USB, Ethernet, parameterizable analog I/O
• Advanced command languages: SCPI, ModBus with LabVIEW and IVI driver support

Applications

• High-power laboratory and production testing requiring programmable DC supplies
• Relay manufacturing and automotive component testing
• Onboard charger and power electronics validation
• Multi-channel parallel systems for 75 kW+ industrial applications
• Data logging and sequencing for automated test procedures

Included Accessories

• Remote sensing plugs (pair)
• USB cable 1.8m (59 ft)
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• AC connector plug (clamp type)
• Set for AC cable strain relief
