EA Elektro-Automatik EA-PS 10360-30 2U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10360-30 2U is a programmable DC power supply from the PS 10000 series, designed for laboratory and industrial applications. It converts AC mains power into regulated DC voltage with efficiency exceeding 96%, featuring true autoranging capabilities that deliver higher voltage at lower currents and higher current at lower voltages for maximum versatility across test applications.

The 2U form factor is optimized for rack mounting with a 5-inch TFT color touch display for intuitive control. Single-phase AC input (110-240V) with active power-factor correction makes it suitable for diverse power environments.

Key Features

• Output voltage 0 to 360V, current 0 to 30A, maximum power 3 kW
• True autoranging flexible output stages for voltage, current, and power optimization
• 5-inch TFT color touch display with intuitive user interface
• High efficiency exceeding 95% with active power-factor correction typical 0.99
• Regulation modes CV, CC, CP with fast crossover
• 16-bit ADCs and DACs with selectable control speed (Normal, Fast, Slow)
• Galvanically isolated Share-Bus for parallel operation
• Master-Slave bus for parallel connection of up to 64 units
• Multiple interfaces: USB, Ethernet, analog input/output
• Command languages SCPI and ModBus with LabVIEW and IVI drivers

Applications

• Laboratory testing and research requiring programmable DC power
• Relay testing and validation during production
• Onboard charger testing for automotive applications
• Multi-unit parallel systems for higher power applications up to 75 kW
• High-speed, high-precision voltage and current control applications

Included Accessories

• Remote sensing plugs (pair)
• USB cable 1.8m (59 ft)
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• Cable tie for strain relief
