EA Elektro-Automatik EA-PS 10360-120 3U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10360-120 3U is a high-power programmable DC laboratory power supply from the PS 10000 series. It converts three-phase grid energy into regulated DC voltage with over 96% efficiency, offering flexible autoranging output stages up to 15 kW. This 3U rack-mount unit is designed for demanding laboratory and industrial applications requiring high voltage, high current, and extensive test capabilities.

Key Features

• Output: 0 to 360 V, 0 to 120 A, up to 15 kW power
• Autoranging output stages with constant power characteristic
• 5-inch TFT color touch display with intuitive user interface
• Regulation modes: CV, CC, CP with fast crossover
• Active Power-Factor-Correction (typical 0.99)
• Efficiency exceeding 96% with 16-bit ADCs and DACs for high resolution
• Input range: 208 V to 480 V ±10% three-phase AC
• Master-Slave bus for parallel operation of up to 64 units
• Galvanically isolated Share-Bus for equal load distribution
• Interfaces: USB, Ethernet, SCPI, ModBus, LabVIEW, IVI drivers

Applications

• High-voltage, high-power laboratory testing and development
• Industrial component and subsystem testing
• Relay and contactor testing in production environments
• Multi-unit parallel systems for extreme power requirements

Included Accessories

• Remote sensing plugs (qty 2)
• USB cable (1.8 m)
• DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• AC connector plug (clamp type)
• AC cable strain relief set
