EA Elektro-Automatik EA-PS 10200-70 3U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10200-70 3U is a high-performance programmable DC laboratory power supply from the PS 10000 series. It converts three-phase grid energy into regulated DC voltage with over 96% efficiency, featuring flexible autoranging output stages. This 3U rack-mount unit is ideal for demanding laboratory and test applications requiring precise power control, high current capability, and extensive interface options.

Key Features

• Output: 0 to 200 V, 0 to 70 A, up to 5 kW power
• Autoranging output stages with constant power characteristic
• 5-inch TFT color touch display with intuitive user interface
• Regulation modes: CV, CC, CP with fast crossover
• Active Power-Factor-Correction (typical 0.99)
• Efficiency exceeding 96% with 16-bit ADCs and DACs for high resolution
• Input range: 208 V to 480 V ±10% three-phase AC
• Master-Slave bus for parallel operation of up to 64 units
• Galvanically isolated Share-Bus for equal load distribution
• Interfaces: USB, Ethernet, SCPI, ModBus, LabVIEW, IVI drivers

Applications

• High-power laboratory testing and development
• Automated test systems for industrial components and relays
• High-current device charging and validation
• Multi-unit parallel systems for extended power ranges

Included Accessories

• Remote sensing plugs (qty 2)
• USB cable (1.8 m)
• DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• AC connector plug (clamp type)
• AC cable strain relief set
