EA Elektro-Automatik EA-PS 10200-210 3U Programmable DC Power Supply
Request a quote
EA Elektro-Automatik EA-PS 10200-210 3U programmable DC power supply with 0-200V/210A output, 15 kW power, autoranging, and three-phase 208-480V AC input.
Product details
| Model | EA-PS 10200-210 3U |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PS 10200-210 3U is a high-performance programmable DC power supply from the PS 10000 series, delivering 0-200V at up to 210A with a maximum power output of 15 kW. This 3U rack-mount supply is optimized for three-phase AC input (208-480V) and provides exceptional power capacity for demanding laboratory and production environments. With autoranging capability and efficiency exceeding 96%, it supports the most demanding test scenarios while maintaining precise voltage and current regulation.
Key Features
- Output range: 0-200V, 0-210A, 15 kW maximum
- Autoranging output stage for flexible power delivery across voltage/current range
- 3U rack-mount form factor (19-inch compatible)
- Input: 208-480V ±10% three-phase AC
- Active Power-Factor-Correction with 0.99 typical and >96% overall efficiency
- Regulation modes: CV (Constant Voltage), CC (Constant Current), CP (Constant Power) with fast crossover
- 5-inch TFT color touch display with touch control and intuitive interface
- 16-bit digital regulation with selectable control speed (Normal, Fast, Slow)
- Master-Slave bus for parallel operation of up to 64 units of all power classes
- Galvanically isolated Share-Bus for proportional load distribution
- Extensive function generator with sequence and logging capabilities
- Alarm and warning management with clear display on master unit
- SCPI and ModBus command languages with LabVIEW and IVI drivers
- USB and Ethernet interfaces for system integration and control
- Remote sensing for accurate output voltage regulation
- Copper rail output connections for scalable parallel systems
Applications
- High-power research and development testing
- Production testing of power electronics and industrial components
- Relay and contactor testing procedures
- Onboard charger (OBC) design and validation
- Battery testing, cycling, and aging studies
- Motor and drive testing
- System integration and production test automation
- Multi-unit system scaling for extended power requirements
Included Accessories
- 1x Power supply device
- 2x Remote sensing plugs
- 1x 1.8 m (59 ft) USB cable
- 1x Set of DC terminal covers
- 1x Sense terminal cover
- 1x USB stick with documentation and software
- 1x AC connector plug (clamp type)
- 1x Set for AC cable strain relief
Specifications
| Voltage Range Selector | 200-299 |
| Output Voltage | 200 V |
| Current Range Selector | 200-499 |
| Output Current | 210 A |
| Power Range Selector | 10,000-19,999 |
| Power Rating | 15 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 208-480 VAC |
| Series | EA-PS 10000 3U Series |
| Number of Outputs | Single Output |
| Special Features | Autoranging |
