EA Elektro-Automatik EA-PS 10200-140 3U Programmable DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10200-140 3U is a high-performance programmable DC power supply from the PS 10000 series, delivering 0-200V at up to 140A with a maximum power output of 10 kW. Designed for three-phase AC input (208-480V), this 3U rack-mount supply provides the power needed for demanding laboratory and production test applications. The autoranging capability and efficiency exceeding 96% make it ideal for complex testing scenarios requiring flexible power delivery across a wide range of voltage and current combinations.

Key Features

• Output range: 0-200V, 0-140A, 10 kW maximum
• Autoranging output stage for flexible power delivery
• 3U rack-mount form factor (19-inch compatible)
• Input: 208-480V ±10% three-phase AC
• Active Power-Factor-Correction with 0.99 typical and >96% overall efficiency
• Regulation modes: CV (Constant Voltage), CC (Constant Current), CP (Constant Power) with fast crossover
• 5-inch TFT color touch display with touch control
• 16-bit digital regulation with selectable control speed (Normal, Fast, Slow)
• Master-Slave bus for parallel operation of up to 64 units of all power classes
• Galvanically isolated Share-Bus for proportional load distribution
• Extensive function generator and alarm/warning management
• SCPI and ModBus command languages with LabVIEW and IVI drivers
• USB and Ethernet interfaces for automation and data logging
• Remote sensing for accurate output voltage regulation
• Copper rail output connections for parallel stacking

Applications

• High-power laboratory testing and research
• Industrial component and device characterization
• Relay and switch testing in production
• Onboard charger (OBC) development and validation
• Battery testing and aging studies
• System-level integration testing
• Automated test system integration
• Power electronics and converter testing

Included Accessories

• 1x Power supply device
• 2x Remote sensing plugs
• 1x 1.8 m (59 ft) USB cable
• 1x Set of DC terminal covers
• 1x Sense terminal cover
• 1x USB stick with documentation and software
• 1x AC connector plug (clamp type)
• 1x Set for AC cable strain relief
