EA Elektro-Automatik EA-PS 10080-60 2U Programmable DC Power Supply
EA Elektro-Automatik EA-PS 10080-60 2U programmable DC power supply with 0-80V/60A output, autoranging capability, over 95% efficiency, and Master-Slave parallel operation.
Product details
| Model | EA-PS 10080-60 2U |
| Manufacturer | EA Elektro-Automatik |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The EA Elektro-Automatik EA-PS 10080-60 2U is a laboratory-grade programmable DC power supply from the PS 10000 series, delivering 0-80V at up to 60A with a maximum power output of 1.5 kW. The autoranging feature maintains full power across various voltage and current combinations, making it ideal for diverse test applications. With a 5-inch TFT color touch display, high efficiency (>95%), and support for parallel operation via Master-Slave bus, this power supply is suited for research, development, and production testing environments.
Key Features
- Output range: 0-80V, 0-60A, 1.5 kW maximum
- Autoranging output stage for flexible voltage and current delivery
- 2U rack-mount form factor (19-inch compatible)
- 5-inch TFT color touch display with intuitive control interface
- Input: 110-240V ±10% single-phase AC
- Active Power-Factor-Correction with 0.99 typical and >95% overall efficiency
- Regulation modes: CV (Constant Voltage), CC (Constant Current), CP (Constant Power) with fast crossover
- 16-bit ADC/DAC with selectable control speed (Normal, Fast, Slow)
- Master-Slave bus for parallel operation of up to 64 units
- Galvanically isolated Share-Bus for load distribution
- SCPI and ModBus command languages with LabVIEW and IVI drivers
- USB Host port for data logging and sequencing
- USB and Ethernet interfaces for remote control and monitoring
- Remote sensing capability for accurate voltage regulation
- Copper busbar output connections
Applications
- Laboratory power supply for research and development
- Component and device testing under defined voltage and current conditions
- Relay testing and verification
- Onboard charger (OBC) testing and validation
- Battery charging, conditioning, and cycling
- System integration and test automation
- Precision current source applications
Included Accessories
- 1x Power supply device
- 2x Remote sensing plugs
- 1x 1.8 m (59 ft) USB cable
- 1x Set of DC terminal covers
- 1x Sense terminal cover
- 1x USB stick with documentation and software
- 1x Cable tie for strain relief
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 80 V |
| Current Range Selector | 50-99.9 |
| Output Current | 60 A |
| Power Range Selector | 1,000-2,499 |
| Power Rating | 1.5 kW |
| Mounting Type | Rack Mount |
| Input Voltage | 110-240 VAC |
| Series | EA-PS 10000 2U Series |
| Number of Outputs | Single Output |
| Special Features | Autoranging |
