EA Elektro-Automatik EA-PS 10060-60 2U DC Power Supply

Overview

The EA Elektro-Automatik EA-PS 10060-60 2U is a programmable DC power supply from the PS 10000 series, designed for laboratory and testing applications with single-phase AC input. With 60V/60A output and 1.5kW maximum power, this compact 2U rackmount unit delivers regulated DC voltage with over 95% efficiency. The autoranging architecture provides flexible voltage/current combinations while maintaining full power output across a wide operating range.

Key Features

• Output: 0–60V DC at 0–60A (1.5kW maximum power)
• Autoranging DC output stages for flexible voltage/current combinations
• High efficiency: >95% with active power-factor correction (typical 0.99)
• Wide AC input range: 110–240V ±10% single-phase with automatic voltage sensing
• Regulation modes: Constant Voltage (CV), Constant Current (CC), Constant Power (CP) with fast crossover
• Digital regulation with 16-bit ADCs/DACs and adjustable control speed (Normal, Fast, Slow)
• 5-inch color TFT touchscreen display with intuitive user interface
• Galvanically isolated Share-Bus and Master-Slave bus for parallel operation of up to 64 units
• Standard interfaces: USB, Ethernet, analog control inputs, galvanically isolated auxiliary connectors

Applications

• Relay and contactor testing during manufacturing
• Onboard charger (OBC) testing and validation
• Laboratory power supply for research and development
• Battery charging and discharging test applications
• System testing and commissioning

Included Accessories

• Power supply device
• 2 remote sensing plugs
• 1.8 m (59 ft) USB cable
• Set of DC terminal covers
• Sense terminal cover
• USB stick with documentation and software
• Cable tie for strain relief
