Tektronix AFG3022C Arbitrary Waveform Generator
Request a quote
Tektronix AFG3022C is a 25 MHz dual-channel arbitrary waveform generator with 14-bit resolution, 250 MS/s sampling, and modulation capabilities.
Product details
| Model | AFG3022C |
| Manufacturer | Tektronix |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The Tektronix AFG3022C is a 25 MHz dual-channel arbitrary waveform and function generator that combines performance, versatility, and intuitive operation for electronic test and design applications. The color 5.6-inch TFT LCD screen displays all relevant waveform parameters and graphical wave shapes, giving users full confidence in their signal settings. Dual-channel capability allows generation of two identical or completely different signals, saving cost and bench space.
Key Features
- 25 MHz output frequency (1 µHz to 25 MHz)
- Dual-channel design for simultaneous signal generation
- 14-bit vertical resolution with 250 MS/s sampling
- 128K arbitrary waveform memory
- 12 standard waveforms plus arbitrary waveform generation
- Variable pulse edge times (independent leading and trailing)
- Modulation: AM, FM, PM, FSK, PWM
- Sweep and burst modes
- Output amplitude up to 20 Vp-p into 50 Ω loads
- Color TFT LCD display (5.6 inches)
- Multi-language interface with intuitive menus
- USB connector on front panel for waveform storage
- USB, GPIB, and LAN connectivity
- LabVIEW and LabWindows/IVI-C drivers
- Highly stable timebase with ±1 ppm drift per year
Applications
- Electronic test and design
- Sensor simulation
- Functional test
- Education and training
Specifications
| Channel/Port Count | 2 |
| High Frequency (range) | 10MHz <= 100MHz |
