IFR 2023B RF Signal Generator
Request a quote
IFR 2023B RF Signal Generator — portable 9 kHz to 2.05 GHz signal generator with excellent spectral purity and comprehensive modulation options.
Product details
| Model | 2023B |
| Manufacturer | IFR |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The IFR 2023B is a portable and lightweight RF signal generator covering frequencies from 9 kHz to 2.05 GHz. It provides excellent spectral purity and a comprehensive range of modulation modes, making it suitable for laboratory, production, and maintenance applications. GPIB and RS-232 interfaces enable integration into automated test systems and basic remote control configurations.
Key Features
- Frequency range: 9 kHz to 2.05 GHz
- Excellent spectral purity
- Linear and logarithmic sweep modes
- Reverse power protection to 50W
- Comprehensive modulation: AM, FM, Phase, Pulse and FSK
- 3.9 kHz Bessel filtered FSK
- Optional +25 dBm RF output
- Optional internal pulse generator
- SINAD measurement option
- GPIB and RS-232 remote control
Applications
- Laboratory signal generation and testing
- Production testing and validation
- Service and maintenance
- Automated test systems (ATE)
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
