Rohde & Schwarz SMT03 Signal Generator
Request a quote
Rohde & Schwarz SMT03 provides 5 kHz to 3 GHz coverage with AM/FM/pulse modulation, ideal for EMS measurements and analog receiver testing.
Product details
| Model | SMT03 (1039.2000.03) |
| Manufacturer | Rohde & Schwarz |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz SMT03 is a RF signal generator designed for conventional analog receiver measurements and EMS (electromagnetic susceptibility) testing. It provides high signal quality with outstanding level accuracy, programmable RF and LF sweeps, and frequency response correction capabilities.
Key Features
- Frequency range: 5 kHz to 3 GHz
- AM, FM, and pulse modulation
- Broadband FM from DC to 8 MHz, broadband phase modulation from DC to 2 MHz
- Programmable RF/LF/level sweeps
- Level correction for external frequency response compensation
- Optional VOR/ILS generator (Option SM-B6) with 0.01° phase resolution
- Optional stereo generator for FM broadcast testing
- Minimum RF leakage with special shielding
- Large backlit LCD display
- 3-year calibration interval
Applications
- EMS signal source for EMC testing
- Conventional analog receiver measurements
- FM broadcast transmitter and receiver testing
- VOR/ILS navigation system simulation
Specifications
| Frequency Range | 5 kHz to 3 GHz |
| Modulation Types | AM, FM, Pulse modulation |
| FM Bandwidth | DC to 8 MHz |
| Phase Modulation Bandwidth | DC to 2 MHz |
| Sweep Types | RF, LF, and level sweeps |
| Optional VOR/ILS Generator | Yes (Option SM-B6) |
| Optional Stereo Generator | Yes (Option SM-B6) |
| Calibration Interval | 3 years |
