RIGOL DSG5206 RF Signal Generator
Request a quote
RIGOL DSG5206 is a 6-channel RF signal generator covering 9 kHz to 20 GHz with phase stability <1° at 10 GHz, 3 ms switching speed, and -133 dBc/Hz phase noise.
Product details
| Model | DSG5206 |
| Manufacturer | RIGOL |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The RIGOL DSG5206 is a 6-channel RF signal generator designed for complex test scenarios including superconducting quantum computation, radar signal generation, MIMO systems, and EMC testing. It operates from 9 kHz to 20 GHz and delivers high-quality signals with accurate level control and wide output power range.
Key Features
- 6-channel configuration with independent channel control
- Frequency range: 9 kHz to 20 GHz
- Channel-to-channel phase stability: <1° at 10 GHz
- Phase offset resolution: 0.01°
- Fast channel switching speed: 3 ms
- Output power up to 25 dBm
- Low phase noise: <-133 dBc/Hz (1 GHz, 10 kHz offset)
Applications
- Superconducting quantum computation testing
- Radar signal generation and simulation
- MIMO system validation
- EMC/EMS testing
Specifications
| Maximum Frequency | 20 GHz |
| Frequency Range | 15.0 - 30.0 |
| Series | DSG5000 Series |
| Includes | Power Cord |
| Number of Channels | 6 |
