RIGOL DSG5128 8-Channel RF Signal Generator
Request a quote
RIGOL DSG5128 is an 8-channel RF generator for 9 kHz–12 GHz with phase stability < 1° at 10 GHz, 3 ms switching speed, and 25 dBm output power.
Product details
| Model | DSG5128 |
| Manufacturer | RIGOL |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The RIGOL DSG5128 is an 8-channel RF signal generator covering 9 kHz to 12 GHz, designed for complex test scenarios such as superconducting quantum computation, radar signal generation, MIMO, and EMS. It provides high-quality signals with accurate signal level and wide output power range, supporting multi-device rack mount configurations.
Key Features
- 8-channel design with multi-device rack mount support
- Frequency range: 9 kHz to 12 GHz
- Channel-to-channel phase stability < 1° at 10 GHz with 0.01° phase offset resolution
- Fast switching speed: 3 ms
- Output power: up to 25 dBm
- Low phase noise: below -133 dBc/Hz at 1 GHz, 10 kHz offset
Applications
- Superconducting quantum computation
- Radar signal generation
- MIMO testing
- EMS testing
Specifications
| Maximum Frequency | 12 GHz |
| Frequency Range | 8.0 - 15.0 |
| Series | DSG5000 Series |
| Includes | Power Cord |
| Number of Channels | 8 |
