Noise Com UFX7110A Noise Generator
Request a quote
Noise Com UFX7110A is a 1.5 GHz noise generator with microprocessor control, 6.25-inch color touchscreen, 127 dB attenuation, and Ethernet/GPIB remote control for precision signal-to-noise testing.
Product details
| Model | UFX7110A |
| Manufacturer | Noise Com |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The Noise Com UFX7000A Series instruments contain an amplified noise source tuned to provide superior flatness with a Gaussian amplitude distribution. The UFX7110A operates from 100 Hz to 1.5 GHz and features microprocessor control with a 6.25-inch color TFT touchscreen display. Noise output power level can be adjusted from 0 to 127 dB in 1 dB increments (optionally 0.1 dB steps). The flexible architecture allows injection of external signals via front panel connectors for controlled noise addition.
Key Features
- Frequency range: 100 Hz to 1.5 GHz
- Output power: +10 dBm
- Noise density: -82 dBm/Hz
- Flatness: ±1.5 dB
- Output: White Gaussian noise
- 127 dB attenuation in 1 dB or optional 0.1 dB steps
- Multiple connector options: Type N, BNC, or SMA
- Optional signal path attenuators and filters (bandpass, lowpass, highpass, notch)
- SP6T switch with four internal/external filter paths
- 6.25-inch color TFT touchscreen for local control
- Remote control via Ethernet or optional GPIB (IEEE-488)
- External signal injection capability
- Impedance: 50 ohms
- Typical VSWR: 1.5:1
Applications
- Eb/No, C/N, and SNR signal testing
- Disk drive testing and characterization
- BER (Bit Error Rate) testing
- Military jamming applications
- GPS receiver testing and validation
- CATV system testing
- Spectrum analyzer calibration
- Filter testing
- EMI testing
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | DC <= 1kHz |
