Keysight M9383A Vector Signal Generator
Request a quote
Keysight M9383A is a modular PXIe vector signal generator covering 1 MHz to 44 GHz with 1% EVM at 28 GHz and 800 MHz bandwidth for 5G applications.
Product details
| Model | M9383A |
| Manufacturer | Keysight |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The Keysight M9383A is a modular PXIe vector signal generator that bridges design validation and manufacturing test. It provides frequency coverage from 1 MHz to 44 GHz with license key-upgradeable frequency options, enabling flexible deployment from immediate test needs to high-volume production.
Key Features
- Frequency coverage: 1 MHz to 44 GHz with license key-upgraded options
- Output power: -90 to +19 dBm at 1 GHz
- Phase noise: -137 dBc/Hz at 1 GHz (20 kHz offset)
- Frequency switching: 10 to 250 microseconds
- IQ modulation bandwidth: 1 GHz to 2 GHz
- Waveform playback memory: 1024 MSa
- Keysight IO Libraries Suite for easy configuration and one-step software install
- Integrated instrument-level VSG soft front panel
Applications
- Design validation and RF component testing
- 5G and Pre-5G signal generation
- LTE/LTE-Advanced, WLAN 802.11, and cdma2000 testing
- Manufacturing test for wireless components
Specifications
| Frequency Range | 1 MHz to 44 GHz |
| Output Power @ 1 GHz | -90 to +19 dBm |
| Phase Noise @ 1 GHz (20 kHz offset) | -137 dBc/Hz |
| Frequency Switching | 10 to 250 microseconds |
| Harmonics @ 1 GHz | -30 to -55 dBc |
| IQ Modulation Bandwidth | 1 GHz to 2 GHz |
| Waveform Playback Memory | 1024 MSa |
| Sweep Modes | List, Step |
| Form Factor | PXIe Card |
| EVM @ 28 GHz | 1% with 800 MHz bandwidth |
