Anritsu 3743A mmWave Module
Request a quote
Anritsu 3743A is a compact high-performance mmWave module using Nonlinear Transmission Line technology, supporting measurements up to 145 GHz.
Product details
| Model | 3743A |
| Manufacturer | Anritsu |
| Category | RF & Microwave Signal Generators |
| Availability | Made to order |
Description
Overview
The Anritsu 3743A is a compact, high-performance millimeter-wave module designed for integration with broadband vector network analyzer systems. It utilizes advanced Nonlinear Transmission Line (NLTL) technology to deliver excellent measurement capabilities across the millimeter-wave spectrum while maintaining a significantly smaller footprint and lower weight than traditional modules.
Key Features
- Frequency coverage extending to 110, 125, or 145 GHz depending on configuration
- Proprietary Nonlinear Transmission Line (NLTL) technology for superior performance
- Compact, lightweight design (0.6 lb vs. 7+ lbs traditional modules)
- 1/50th the volume of conventional mmWave modules
- Excellent calibration and measurement stability
- Compatible with VectorStar ME7838 broadband VNA systems
- Supports noise figure measurements to 125 GHz
Applications
- Millimeter-wave component and device characterization
- High-frequency semiconductor testing
- Broadband transmission line and waveguide measurements
- 5G and mmWave circuit validation and analysis
Specifications
| Technology | Nonlinear Transmission Line (NLTL) |
| Weight | 0.6 lb |
| Frequency Coverage | Up to 145 GHz |
| Form Factor | 1/50 the volume of conventional modules |
