Keysight N1810TL/004/124/201 Latching Coaxial Switch
Request a quote
Keysight N1810TL/004/124/201 is a DC-4 GHz latching coaxial switch with 50 Ω termination, 24 V coil drive, and D-subminiature 9-pin connectors for RF signal routing.
Product details
| Model | N1810TL/004/124/201 |
| Manufacturer | Keysight |
| Category | Modular DC Supplies |
| Availability | Made to order |
Description
Overview
The Keysight N1810TL/004/124/201 is a terminated latching electromagnetic coaxial switch configured for DC to 4 GHz operation with 24 V coil drive and D-subminiature 9-pin female connectors. With internal 50 Ω termination, this switch delivers excellent RF isolation and low insertion loss for signal routing and test applications in RF and microwave systems.
Key Features
- Latching SPDT coaxial switch with 50 Ω internal termination
- DC to 4 GHz frequency range (004 configuration)
- 24 V coil voltage drive (124 configuration)
- D-subminiature 9-pin female connectors (201 configuration)
- SMA female RF connectors
- Superior RF isolation and low insertion loss
- Excellent insertion loss repeatability to 2 million cycles
- Optional position indicator
Applications
- Signal routing and switching in RF measurement systems
- Signal path reversal for bidirectional RF applications
- RF calibration port switching and control
- Precision RF and microwave test systems
Specifications
| Series | N1810 Series |
