Tektronix FCA3020 Timer/Counter/Analyzer

Overview

The Tektronix FCA3020 is a versatile timer/counter/analyzer that combines frequency, period, and timing measurements in a single instrument. With industry-leading resolution and fast data acquisition, it delivers accurate signal characterization for applications ranging from component testing to system validation.

The instrument includes advanced analysis features such as measurement statistics, histograms, and trend analysis, enabling engineers to quickly identify signal characteristics and verify system performance. Its fast throughput—up to 250,000 measurements per second—reduces test time significantly compared to conventional counters.

Key Features

• 300 MHz measurement on A and B channels, 20 GHz on C channel
• 100 ps single-shot time resolution and 12-digit/second frequency resolution
• Phase resolution of 0.001° and voltage resolution of 3 mV
• Comprehensive automated measurements: frequency, period, ratio, time interval, pulse width, rise/fall time, phase angle, duty cycle, voltage extrema
• Zero dead-time measurement with continuous time-stamping for critical cycle tracking
• Hysteresis compensation reduces trigger error to 2.5 mV (vs. typical 15–20 mV)
• Up to 250,000 measurement results per second stored in internal memory
• GPIB and USB interfaces for real-time data streaming and remote control
• Optional high-stability oven time base for long-term frequency accuracy
• Optional TimeView Software for modulation domain analysis
• Three-year warranty

Applications

• Precision frequency and time interval measurements in electronics testing
• Jitter analysis and verification in digital systems and data communications
• Phase and timing relationship measurements in RF and microwave applications
• Statistical analysis and characterization of periodic signals
• Automated measurement and monitoring in production test environments
