Keysight 773D/001 Coaxial Directional Coupler
Request a quote
Keysight 773D/001 is a coaxial directional coupler for broadband RF measurements from 2 to 18 GHz with 20 dB nominal coupling and ±1.0 dB variation.
Product details
| Model | 773D/001 |
| Manufacturer | Keysight |
| Category | Directional Couplers |
| Availability | Made to order |
Description
Overview
The Keysight 773D/001 is a coaxial directional coupler designed for broadband RF measurements across the 2 to 18 GHz frequency range. This coupler is ideal for leveling broadband sources when used with the Keysight 8474B detector. The broadband design enables a single test setup and calibration across the entire frequency range.
Configuration
Configuration (001): Primary line N(f), N(f); Auxiliary arm N(f)
Key Features
- Superior RF performance
- Nominal coupling: 20 dB
- Maximum coupling variation: ±1.0 dB
- Directivity: 30 dB to 12.4 GHz, 27 dB to 18 GHz
- Coaxial N-type connectors
Applications
- Broadband RF swept measurements
- Source leveling and power monitoring
- RF test and measurement systems
Specifications
