Keysight N9917B Cable and Antenna Analyzer
Request a quote
Keysight N9917B FieldFox microwave analyzer covers 30 kHz to 18 GHz with integrated cable, antenna, and network analysis plus 100 MHz real-time spectrum capability.
Product details
| Model | N9917B |
| Manufacturer | Keysight |
| Category | Cable & Antenna Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9917B FieldFox is a next-generation handheld microwave analyzer designed for field testing and troubleshooting of wideband, microwave, and millimeter-wave communications systems. It provides integrated RF and microwave measurement capabilities covering 30 kHz to 18 GHz with 100 MHz gap-free real-time bandwidth.
Key Features
- Frequency coverage: 30 kHz to 18 GHz (expandable to 110 GHz with downconverter)
- 100 MHz gap-free real-time bandwidth for capturing elusive signals
- Cable and antenna analyzer (standard)
- Vector network analyzer with full 2-port S-parameter measurement (115 dB dynamic range)
- Spectrum analyzer with ±0.3 dB accuracy without warmup
- Over-the-air demodulation for 5G NR and LTE
- Integrated GPS/GNSS for geolocation and timestamping
- Lightweight at 3.4 kg (7.4 lb)
Applications
- 5G network deployment and field testing
- Cable and antenna condition verification
- RF signal analysis and interference troubleshooting
- Field strength measurement
- AM/FM tune and listen
Specifications
| Frequency | 18 GHz |
| Series | B-Series |
| Backlight | Yes |
| Battery Life | 4.5 hrs. |
| Battery Type | Lithium-Ion |
| Connector Type | Type-N (f) |
| Dimensions | 11.5 x 7.4 x 3.2 in. |
| Display | 6.5" Transflective Color LCD-LED |
| Dynamic Range | 114 dB |
| Frequency Range | 30 kHz to 18 GHz |
| Function | CAT, VNA, SA |
| Includes | AC/DC adapter, Localized power cord, Rechargeable Li-ion battery, Soft carrying case with backpack and shoulder straps, Quick Reference Guide |
| Number of Ports | 2 |
| Operating Temperature Range | 0 to 55°C |
