Keysight N9914C Cable and Antenna Analyzer
Request a quote
Keysight N9914C FieldFox portable RF analyzer for cable and antenna testing, VNA, and spectrum analysis from 3 kHz to 6.5 GHz with 115 dB dynamic range.
Product details
| Model | N9914C |
| Manufacturer | Keysight |
| Category | Cable & Antenna Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9914C FieldFox is a lightweight, battery-powered RF analyzer designed for field testing of RF devices including cables, antennas, filters, and amplifiers. This C-Series model offers extended frequency coverage starting from 3 kHz and superior noise performance, making it ideal for modern wireless applications including 5G and LTE measurements.
Key Features
- Integrated three-in-one analyzer: Cable and Antenna Tester (CAT), Vector Network Analyzer (VNA), and Spectrum Analyzer (SA)
- Frequency range: 3 kHz to 6.5 GHz (CAT/VNA/SA)
- Superior displayed average noise level: -160 dBm from 3 kHz to 6.5 MHz (C-Series advantage)
- 115 dB dynamic range for simultaneous four S-parameter measurements
- Built-in variable voltage DC bias source
- Anti-glare 6.5-inch LCD display with LED backlight
- Built-in GPS receiver for location tracking
- Field-swappable battery: up to 4 hours operation
- Software-upgradeable frequency, bandwidth, and measurement capabilities
- USB and SCPI over LAN control
- Rugged design: meets MIL-PRF-28800F Class 2, MIL-STD-810G, and IP67
- USB Power Sensor support for extended measurement options
Applications
- Cable and antenna characterization and field testing
- Filter and amplifier performance verification
- 5G and LTE over-the-air (OTA) signal measurements
- Network analysis and reflection coefficient measurement
- Spectrum analysis and modulation identification
Included Accessories
- AC/DC power adapter
- Localized power cord
- Rechargeable lithium-ion battery
- Soft carrying case with backpack and shoulder straps
- Quick Reference Guide
Specifications
| Frequency | 6.5 GHz |
| Series | C-Series |
| Backlight | Yes |
| Battery Life | 4 hrs. |
| Battery Type | Lithium-Ion |
| Connector Type | Type-N (f) |
| Dimensions | 11.5 x 7.4 x 3.2 in. |
| Display | 6.5" Transflective Color LCD-LED |
| Dynamic Range | 104 dB |
| Frequency Range | 3 kHz to 6.5 GHz |
| Function | CAT, VNA, SA |
| Includes | AC/DC adapter, Localized power cord, Rechargeable Li-ion battery, Soft carrying case with backpack and shoulder straps, Quick Reference Guide |
| Number of Ports | 2 |
| Operating Temperature Range | -10 to 55°C |
