Keysight S97010B Time Domain Analysis Option
Request a quote
Keysight S97010B enables time domain analysis for vector network analyzers, providing error-corrected reflection/transmission responses, gating, and filter tuning.
Product details
| Model | S97010B/R-A4C-001-L |
| Manufacturer | Keysight |
| Category | Analyzer Options & Accessories |
| Availability | Made to order |
Description
Overview
The Keysight S97010B Time Domain Analysis option enables network analyzers to view reflection and transmission responses in time or distance domain. This application transforms frequency domain data to time domain or vice versa, facilitating precise measurements and device characterization.
Key Features
- Fully error-corrected time domain reflection or transmission response
- Gating capability to remove unwanted responses from test fixtures and cables
- Transform frequency domain to time domain or time domain to frequency domain
- Compatible with all USB vector network analyzers
- Beneficial for tuning many filter types, including cavity-resonator filters
Applications
- Tuning filters and cavity-resonator designs
- Gating out fixture and cable responses
- Characterizing transmission line impedance
- Time/distance domain measurements and analysis
Specifications
| Series | Streamline Series |
