Siglent SVA1075X Spectrum and Vector Network Analyzer

Overview

The Siglent SVA1075X is the highest-bandwidth spectrum and vector network analyzer in the SVA1000X series, extending frequency coverage to 7.5 GHz. It delivers comprehensive RF signal analysis and network characterization with exceptional sensitivity, advanced measurement modes, and optional capabilities including distance-to-fault location, vector signal modulation analysis, and EMI filtering for diverse RF testing applications in research, development, and production environments.

Key Features

• Spectrum analyzer: 9 kHz to 7.5 GHz with <-98 dBc/Hz phase noise at 10 kHz offset (1 GHz, typical)
• Vector network analyzer: 100 kHz to 7.5 GHz for comprehensive S-parameter measurement
• Exceptional sensitivity: -165 dBm/Hz Displayed Average Noise Level (typical)
• Level measurement uncertainty <0.7 dB with 1 Hz minimum resolution bandwidth
• Preamplifier and tracking generator included as standard
• 10.1-inch multi-touch display with mouse and keyboard support
• Web browser remote control on PC and mobile terminals
• Vector network analyzer modes: S11 and S21 measurements from 100 kHz to 7.5 GHz with multi-format overlay display
• Optional modulation analysis: AM/FM, ASK/FSK/PSK/MSK/QAM vector signal modulation with EVM evaluation

Applications

• Broadcast monitoring and RF network characterization
• S-parameter measurement and cable/antenna testing
• Analog and digital signal modulation analysis
• EMI pre-compliance testing
• Circuit design and failure analysis with optional distance-to-fault
• Research, development, education, production, and maintenance

Optional Features

• Distance to Fault (DTF) locator for cable fault identification
• Vector Signal Modulation Analysis Mode for advanced modulation characterization
• EMI Filter and Quasi-Peak Detector Kit for compliance testing
• Advanced Measurement Kit for specialized analysis capabilities
