Rohde & Schwarz ZNLE3-COM Vector Network Analyzer Package

Overview

The Rohde & Schwarz ZNLE3-COM is a promotional package for channel partners, combining the ZNLE3 two-port vector network analyzer with the ZNLE-B100 low-frequency extension and ZN-Z135 calibration kit. This complete solution extends the analyzer's frequency range down to 100 kHz, enabling measurements on components across a wider frequency band. The package includes four years of warranty and manufacturer calibration coverage on repair.

Key Features

• ZNLE3 base unit: 1 MHz to 3 GHz (extendable to 100 kHz with B100 option)
• Two-port vector network analyzer with full S-parameter test set (S11, S21, S12, S22)
• Wide dynamic range: up to 120 dB (typical)
• Low trace noise: 0.001 dB typical at 10 kHz IFBW
• Measurement bandwidths: 1 Hz to 500 kHz
• Fast measurements: 8.7 ms for 401 points (100 kHz IFBW, 200 MHz span)
• 10.1" WXGA touchscreen with drag-and-drop interface
• Standalone operation with integrated Windows 10 OS and SSD storage
• LAN interface standard; optional GPIB for remote control
• Included: ZNLE-B100 low-frequency extension (100 kHz lower end)
• Included: ZN-Z135 calibration kit
• Extended warranty: 4 years with manufacturer calibration coverage

Applications

• Extended frequency range testing: 100 kHz to 3 GHz
• Low-frequency component characterization (filters, cables, transformers)
• Production and R&D environments requiring calibration kit
• Channel partner solutions with extended warranty coverage
