Rohde & Schwarz ZNLE3 Vector Network Analyzer

Overview

The Rohde & Schwarz ZNLE3 is a compact two-port vector network analyzer designed for bidirectional S-parameter measurements on passive RF and microwave components. The analyzer features a 10.1" WXGA touchscreen with an intuitive drag-and-drop user interface, allowing configuration and measurement without requiring an external PC. With a frequency range of 1 MHz to 3 GHz and dynamic range up to 120 dB, it delivers accurate and repeatable measurements across its operating band.

As a standalone instrument with integrated Windows 10 PC platform and solid-state storage, the ZNLE3 provides fast boot time, reliable operation, and low trace noise of 0.001 dB typical at 10 kHz bandwidth. The built-in calibration wizard supports both manual and automatic calibration units, making it ideal for production and R&D environments where speed and accuracy are essential.

Key Features

• Frequency range: 1 MHz to 3 GHz
• Two-port configuration with full S-parameter test set (S11, S21, S12, S22)
• Wide dynamic range: up to 120 dB (typical)
• Low trace noise: 0.001 dB typical at 10 kHz IFBW
• Measurement bandwidths: 1 Hz to 500 kHz
• Fast measurements: 8.7 ms for 401 points (100 kHz IFBW, 200 MHz span)
• Compact size: 24 cm depth, 6 kg weight
• 10.1" WXGA touchscreen with drag-and-drop interface
• Standalone operation with integrated Windows 10 OS and SSD storage
• LAN interface standard; optional GPIB for remote control
• Integrated calibration wizard with auto-calibration unit support
• Undo/redo functionality for quick measurement adjustments

Applications

• S-parameter and reflection coefficient measurements on passive components
• Filter and cable characterization in RF/microwave design
• Production testing with fast, accurate measurements
• Component quality assurance in manufacturing environments
