Rohde & Schwarz ZNL6 Vector Network Analyzer
Rohde & Schwarz ZNL6 is a portable 2-port vector network analyzer covering 5 kHz to 6 GHz with optional integrated spectrum analyzer, RF power meter support, and compact 6–8 kg weight.
Product details
| Model | ZNL6 |
| Manufacturer | Rohde & Schwarz |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz ZNL6 is a portable, 2-port vector network analyzer covering frequencies from 5 kHz to 6 GHz. It offers a unique modular option concept that allows configuration with integrated spectrum analyzer and RF power meter capabilities, providing a multifunctional test instrument in a single compact package.
The 3-in-1 design reduces test complexity by combining vector network analysis, spectrum analysis, and power measurement capabilities. The compact, battery-powered design makes it ideal for laboratory, production, and field use across research facilities, service centers, and universities.
Key Features
- Wide frequency range: 5 kHz to 6 GHz
- 2-port vector network analyzer for bidirectional measurements
- Optional fully integrated spectrum analyzer with independent CW signal generator option
- Optional external RF power sensor support
- Multitouch user interface with intuitive display
- Portable and compact: 6–8 kg weight, less than 24 cm depth
- Optional battery pack for field deployment
- Windows 10 operating system
Applications
- Component and subsystem RF testing
- Research and development
- Manufacturing and production testing
- Service and field measurement
- University and training environments
Specifications
| Number of Ports | 2 |
| Maximum Frequency | 6 GHz |
| Minimum Frequency | 5 kHz |
| Type | Benchtop |
| Series | ZN-L Series |
| Alternate Product Number | 1323.0012.06 |
| Connector Type | N (f) |
