Rohde & Schwarz ZNL4 Vector Network Analyzer
Request a quote
Rohde & Schwarz ZNL4 is a 2-port vector network analyzer, 5 kHz to 4.5 GHz, with Type-N connectors and optional spectrum analyzer capability.
Product details
| Model | ZNL4 |
| Manufacturer | Rohde & Schwarz |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz ZNL4 is a compact two-port vector network analyzer designed for laboratory, field service, and production environments. It extends the frequency coverage to 4.5 GHz and offers flexible options including spectrum analyzer capability and extended power range, making it suitable for a wide range of RF and microwave applications requiring higher frequency capability than the ZNL3.
Key Features
- Two-port vector network analyzer for bidirectional measurements
- Frequency coverage 5 kHz to 4.5 GHz
- Type-N female connectors
- Wide dynamic range of typical 130 dB
- Output power range from –40 dBm to typical +3 dBm
- Measurement bandwidths from 1 Hz to 500 kHz
- Fast measurements: 16.7 ms for 401 points
- Compact size and low weight (approximately 6 kg)
- Multitouch screen interface
- Optional battery pack for portable field use
- Windows 10 operating system
Applications
- Component characterization and impedance measurements
- Antenna and transmission line testing
- Filter and amplifier design validation
- Field service and on-site troubleshooting
- Production testing and quality assurance
- Higher-frequency RF and microwave applications
Specifications
| Series | ZN-L Series |
