Rohde & Schwarz ZNL3 Vector Network Analyzer

Overview

The Rohde & Schwarz ZNL3 is a compact vector network analyzer that reduces investment costs through its unique option concept. The base model supports frequencies from 5 kHz up to 3 GHz and can be extended with a fully integrated spectrum analyzer and RF power meter support. Instead of investing in multiple instruments, research labs, service centers, universities, and production facilities benefit from a single, compact instrument that offers higher measurement speed and better RF performance than dedicated instruments in its class.

Key Features

• Two-port vector network analyzer for bidirectional measurements
• Optional spectrum analyzer with CW signal generator capability
• RF power meter support for measurements up to 3 GHz
• Multitouch screen user interface
• Fully portable design with optional battery pack
• Compact size and low weight (6 kg to 8 kg)
• Wide dynamic range of typical 130 dB
• Output power range from –40 dBm to typical +3 dBm
• Measurement bandwidths from 1 Hz to 500 kHz
• Fast measurements: 16.7 ms for 401 points
• Windows 10 operating system

Applications

• Circuit and component characterization
• Filter and amplifier design and validation
• Antenna and transmission line testing
• Field service and maintenance
• Production test and quality control
• Research and development in RF/microwave engineering

Included Accessories

• Calibration kit
• User documentation and support materials
