Rohde & Schwarz ZNA67 Vector Network Analyzer

Overview

The Rohde & Schwarz ZNA67 is a premium 2-port vector network analyzer from the high-end ZNA series. Operating from 10 MHz to 67 GHz with 1.85 mm connectors, it combines exceptional RF performance with a unique touch-based operational concept. The instrument features outstanding stability, low trace noise, and excellent raw system data, making it ideal for development and production applications requiring high accuracy at millimeter-wave frequencies in aerospace, defense, and satellite applications.

Key Features

• Frequency range: 10 MHz to 67 GHz with 1.85 mm connectors
• 2-port configuration
• Up to four internal, phase-coherent sources for flexible signal control
• Up to eight independent receivers for multi-channel phase measurements
• Two independent touchscreens with drag-and-drop interface
• Wide dynamic range for characterizing high-blocking devices
• DUT-centric approach with automatic settings optimization
• Optional software packages for spectrum analysis, time domain analysis, and mixer measurements
• Optional frequency extension up to 1.1 THz with external converters

Applications

• Development and production of millimeter-wave components
• High-frequency RF and microwave device characterization
• Aerospace and defense component testing
• Satellite communication systems
• High-accuracy metrology

Included Accessories

• Mechanical calibration and verification kits
• Test cables and torque wrenches
• NRP power sensor family support
