Rohde & Schwarz ZNA43 Vector Network Analyzer
Request a quote
Rohde & Schwarz ZNA43 vector network analyzer, 10 MHz to 43.5 GHz, 2 ports with 2.4 mm connectors, excellent stability and low trace noise for advanced RF measurements.
Product details
| Model | ZNA43 (1332.4500.43) |
| Manufacturer | Rohde & Schwarz |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz ZNA43 is a high-end vector network analyzer extending the ZNA series into the millimeter-wave domain, covering 10 MHz to 43.5 GHz. Designed for precise characterization of RF and microwave components requiring higher frequency coverage, the ZNA43 maintains exceptional stability, low trace noise, and outstanding measurement accuracy. Its dual-touchscreen interface and DUT-centric approach make it ideal for aerospace, satellite, and millimeter-wave component development.
Key Features
- Frequency range: 10 MHz to 43.5 GHz with 2.4 mm connectors
- 2-port configuration for flexible device characterization
- Excellent RF performance with wide dynamic range
- Up to four phase-coherent sources for flexible measurement configurations
- Two internal local oscillator sources for fast mixer measurements
- Unique dual-touchscreen operation with DUT-centric approach
- Millimeter-wave converter support with optional ZNA-K8 software
- Supports time domain analysis, scalar/vector mixer measurements, and spectrum analysis
Applications
- Millimeter-wave component and module development
- High-frequency device characterization up to 43.5 GHz
- Aerospace and satellite system component validation
- Advanced mixer and frequency converter measurements
Included Accessories
- Mechanical calibration and verification kits
- Automatic and inline calibration units available as options
- Test cables and torque wrenches
Specifications
| ZNA43 | 1332.4500.432 ports10 MHz to 43.5 GHz2.4 mm(m) |
