Rohde & Schwarz ZNA26 Vector Network Analyzer

Overview

The Rohde & Schwarz ZNA26 is a high-end vector network analyzer designed for precise characterization of RF and microwave components in development and production environments. The 2-port configuration covers 10 MHz to 26.5 GHz with exceptional stability, low trace noise, and outstanding raw data accuracy suitable for metrology-grade measurements. Its intuitive dual-touchscreen interface and DUT-centric measurement approach make it an ideal choice for aerospace, satellite, and advanced component development applications.

Key Features

• Frequency range: 10 MHz to 26.5 GHz with 3.5 mm connectors
• Excellent RF performance with wide dynamic range for high-blocking devices
• Up to four phase-coherent sources with independent frequency control
• Two internal local oscillator sources for fast mixer measurements
• Unique dual-touchscreen operation with DUT-centric approach and drag-and-drop configuration
• Multiple measurement modes: scalar/vector mixer analysis, time domain (TDR), and spectrum analysis
• Optional direct channel access for external test setups and system integration

Applications

• Component and module development for aerospace and satellite systems
• Production testing of passive and active RF/microwave devices
• Metrology-grade measurements and calibration verification
• Frequency converter and mixer characterization with intermodulation analysis

Included Accessories

• Mechanical calibration and verification kits
• Automatic and inline calibration units available as options
• Test cables and torque wrenches
