Rohde & Schwarz ZN-Z52 Automatic Calibration Unit
Request a quote
Rohde & Schwarz ZN-Z52 automatic VNA calibration unit with 50-ohm impedance, 100 kHz to 26.5 GHz frequency range, and 4 3.5mm(f) ports for multiport calibration.
Product details
| Model | ZN-Z52 (1335.6991.30) |
| Manufacturer | Rohde & Schwarz |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz ZN-Z52 series represents an advanced generation of automatic VNA calibration units, covering a broad frequency range from 100 kHz to 26.5 GHz. The ZN-Z52 model features four 3.5mm female (3.5mm(f)) connectors with 50-ohm characteristic impedance, enabling reliable multiport calibration for vector network analyzers. This unit requires virtually no warm-up time and features USB auto-detection for seamless integration with compatible Rohde & Schwarz VNA systems.
Key Features
- Frequency range: 100 kHz to 26.5 GHz
- Four 3.5mm female (3.5mm(f)) connectors with 50-ohm impedance
- Automatic detection and configuration via USB
- Plug-and-play operation with minimal setup required
- Multiport calibration support for complex network testing
- Support for switch matrix calibration systems
- Virtually no warm-up time required
- Compatible with R&S ZVA/T, ZNB/T, ZNC, ZND, ZNL analyzers
Applications
- Multiport characterization of RF and microwave components
- Network analyzer calibration and verification
- High-frequency component testing up to 26.5 GHz
- Cable and connector characterization
- Amplifier and filter development and testing
- Switch matrix system calibration
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
| Connector Type | 3.5mm-Female (Plug) |
