Rohde & Schwarz ESRP3 EMI Test Receiver
Rohde & Schwarz ESRP3 is an EMI receiver covering 9 kHz to 3.6 GHz with CISPR-compliant detectors, FFT time-domain scanning, and compact design for precompliance testing.
Product details
| Model | ESRP3 (1316.4500.03) |
| Manufacturer | Rohde & Schwarz |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz ESRP3 is a compact EMI test receiver for precompliance measurements in the 9 kHz to 3.6 GHz range. It combines sophisticated EMI testing capabilities with full spectrum analysis, offering both conventional stepped-frequency and FFT-based time-domain scanning to optimize measurement speed and accuracy.
The ESRP3 is ideal for development labs and testing facilities requiring compliance with CISPR 16-1-1, MIL-STD-461, and other EMI standards. Its intuitive touchscreen interface and comprehensive measurement automation make it suitable for both experienced engineers and technicians new to EMI testing.
Key Features
- Frequency coverage from 9 kHz to 3.6 GHz
- EMI test receiver and spectrum analyzer in a single unit
- CISPR 16-1-1 compliant detectors (quasi-peak, CISPR-average, RMS-average)
- Multiple standardized resolution bandwidths (200 Hz, 9 kHz, 120 kHz, 1 MHz)
- Fast FFT-based time-domain scanning for accelerated measurements
- Built-in preselection and preamplifier for improved dynamic range
- Touchscreen display with straightforward menu navigation
Applications
- Precompliance EMI/RFI testing and certification preparation
- Diagnostic measurements during product development cycles
- Spectrum analysis for general laboratory use
- Emissions compliance verification per CISPR, EN, and military standards
Included Accessories
- Power cable
- Probe power cable
- Quick start guide
- CD-ROM with operating and service manuals
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
Request a quote
