Keysight P9375B Vector Network Analyzer
Request a quote
Keysight P9375B is a compact, portable 2-port vector network analyzer with 100 kHz to 26.5 GHz coverage, 115 dB dynamic range, and Thunderbolt 3 interface.
Product details
| Model | P9375B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P9375B is a compact, portable vector network analyzer (VNA) designed for cost-effective network analysis of passive components. Packaged in a small chassis and controlled via an external computer with Thunderbolt 3 interface, the P9375B delivers the measurement capabilities of a benchtop VNA in a highly portable form factor. It provides the same intuitive GUI and SCPI command set as Keysight's high-performance VNAs, enabling easy integration into existing test workflows.
Key Features
- Frequency range: 100 kHz to 26.5 GHz
- 2-port configuration with 3.5 mm female connectors
- Dynamic range greater than 115 dB
- Low trace noise: 0.0015 dB rms at 10 kHz IFBW
- Fast measurement cycle time: less than 15 msec for 2-port measurements at 201 points
- Excellent temperature stability: less than 0.005 dB/°C
- Output power: 8 dBm
- Lightweight: 1.88 kg for easy portability
- Thunderbolt 3 interface for high-speed data transfer
- Compatible with Keysight electronic calibration (ECal) modules and mechanical calibration kits
Applications
- Passive component characterization (filters, amplifiers, couplers)
- Cable and connector testing and validation
- Time domain reflectometry (TDR) measurements with enhanced analysis
- Fixture removal and de-embedding for accurate measurements
- Field testing and portable network analysis
- Multi-location testing with easy VNA sharing between teams
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
| Connector Type | 3.5mm-Female (Plug) |
