Keysight P9373B Vector Network Analyzer
Request a quote
Keysight P9373B is a compact 2-port vector network analyzer with 9 kHz to 14 GHz frequency coverage, Thunderbolt 3 interface, and 115 dB dynamic range for portable RF testing.
Product details
| Model | P9373B |
| Manufacturer | Keysight |
| Category | Vector Network Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight P9373B is a compact 2-port vector network analyzer in the Streamline Series, offering excellent performance in general-purpose network analysis of passive components. With Thunderbolt 3 connectivity and frequency coverage from 9 kHz to 14 GHz, it delivers measurement capabilities comparable to larger benchtop systems while minimizing test setup size, cost, and operational complexity.
Key Features
- Frequency range: 9 kHz to 14 GHz with 1 Hz resolution
- 2-port configuration with 3.5 mm (female) test port connectors
- Thunderbolt 3 interface for fast host PC communication
- Dynamic range: 115 dB at 10 Hz intermediate frequency bandwidth (IFBW)
- Trace noise: 0.0015 dB rms at 10 kHz IFBW
- Output power: 8 dBm across frequency range
- Temperature stability: 0.005 dB/°C
- Measurement cycle time: less than 15 msec for 2-port measurements at 201 points (typical)
- Compact, lightweight design: 1.88 kg
- Supports all Keysight mechanical calibration kits and electronic calibration (ECal) modules
Applications
- Characterization of passive RF and microwave components
- Time-domain reflectometry (TDR) analysis with automatic fixture removal
- Portable network analysis between test locations
- Quality control and manufacturing test
- Educational and research applications
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
